Petkum - IMO 9386988

Westerschelde 21 January 2016

Name

PETKUM

Type

Containership - Equipped for carriage of dangerous goods

IMO-number

9386988

Call sign

V2DP5

Flag

Antigua & Barbuda

Port of registry

St. John's

GT

15.633 t

Suez: 46.526,76 t

DWT

Summer: 16.975,3 t

NT

6.717 t

Suez: 37.729,52 t

Number of 20ft containers

On deck: 910

In hold: 492

Total: 1.402

Number of 40ft containers

In hold: 230 + 42 TEU

On deck: 409 + 64 TEU

Total: 639 + 106 TEU

Container capacity 14t

870

Reefer capacity

On deck: 124

In hold: 126

250 plugs (440 V - 60 Hz - 3 phase)

Length

161,09 m overall

151,00 m between perpendiculars

151,35 m registered

Breadth

25,43 m extreme

25,00 m moulded

Draught

Summer: 9,90 m

Height above keel

50,20 m

Forecastle

33,39 m

Poop

28,98 m

Freeboard

4.300 mm

Depth

13,90 m

Speed

Max: 19,5 knots

Economic: 16,0 knots

Built

2008

Keel laid

31/10/2007

Launch date

10/04/2008

Date of completion

19/09/2008

Builder

Shandong Province Weihai Shipyard

95 Haibin Road (N)

264200 Weihai , Shandong

People's Republic of China

Yard number

CZ049

Hull material

Shipbuilding steel (standard)

Hull type

Single hull

Double bottom

Watertight bulkheads

7

Continuous decks

1

Main engine

1x MAN-B&W 6S60MC-C - 2 stroke single acting 6 cylinder 600 x 2.400 mm combustion engine Mcr 13.560 kW / 18.436 hp at 105,0 rpm

Year of manufacture: 2007

Manufacturer: STX Engine Co., Ltd.

80, Seongsan-dong

Changwon , Gyeongsangnam 641-315

Republic of Korea

Propellers

1x Fixed pitch propeller - aft at 105, rpm

Boilers

1x Steam boiler, oil fired - 9,0 bar

Heating surface: 19,0 m²

1x Steam boiler, exhaust gas heated - 9,0 bar

Heating surface: 349,0 m²

Year of manufacture: 2006

Manufacturer: Aalborg Industries Ltd.

86 Guangzhou Road North Jiaozhou

266300 Qingdao , Shandong

People's Republic of China

Electric installations

3x Plans each 450/230 V - 1.200 kVA

1x Plant 450 V - 375 kVA

Generators

3x MaK 6M20C - 4 stroke 6 cylinder 200 x 300 mm diesel engines each Mcr 1.140 kw connected with generators each 960 kW - 450/120 Volt

Emergency generator

1x Volvo Penta D12D AMG diesel generatorset 375 kVA

Compressed air receivers

2x Receivers each 6.000 litres - 30,0 bar

1x Receiver 320 litres - 30,0 bar

1x Receiver 1.000 litres - 10,0 bar

1x Receiver 320 litres - 10,0 bar

Bow thruster

1x Transverse thruster - 800 kW / 1.088 bhp, forward

Number of holds

4x Holds divided in 8 compartments

Dimension:

Hold 1: 24,15 x 15,70 x 17,20 m, narrowing

Holds 2-6: 12,48 x 20,70 x 14,30 m

Hold 7: 6,24 x 20,70 x 14,30 m

Number of hatches

8x Hatches with 14 hatch covers TTS pontoon type

Dimensions:

Hatches 1-2: 6,24 x 15,70 m

Hatches 3-13: 6,24 x 20,70 m

Hatch type

Hatch covers are longitudinally divided for non-sequential opening and bay-wise operation also inside holds; it is not necessary to empty complete deck to reach containers in hold

Floor space

Under deck: 1.662 m² / 17.889 ft²

On deck: 1.873 m² / 20.160 ft²

Tank capacities

Fuel oil: 1.600 m³

Diesel oil: 150 m³

Ballast: 8.053,0 m³

Fresh water: 272,6 m³

Anchor equipment

3x Anchors weight each 6.900 kg

Length: 605,00 m

Diameter: 64 mm

Cargo gear

2x Mac Gregor single deck midships container cranes - SWL 45,00 t each

Accommodation

20 persons, 20 cabins

Manager

Briese Schiffahrts GmbH & Co. KG

Hafenstr. 12

26789 Leer

Federal Republic of Germany

Registered owner

Briese Schiffahrts GmbH & Co. KG MS "PETKUM"

Hafenstr. 12

26789 Leer

Federal Republic of Germany

Renamed

2021 Cap Salia

Antigua & Barbuda, St. John’s - Call sign: V2DP5

Reg. Owner: Briese Schiffahrts GmbH & Co. KG MS "Neuburg"

Manager: Briese Dry Cargo GmbH & Co. KG

2023 Petkum

Antigua and Barbuda, St. John's - Call sign: V2DP5

Owner: Briese Schiffahrts GmbH & Co. KG MS "Neuburg" - Germany

Manager: Briese Dry Cargo GmbH & Co. KG - Germany

Latest data adjustment

08 July 2024
