Westerschelde 12 March 2019 |
 |
 |
 |
 |
 |
||||
| Zeebrugge 24/03/18 | Zeebrugge 24/03/18 | Vlissingen 12/07/17 | Westerschelde 16/02/19 | Westerschelde 28/02/18 | ||||
|
Name |
NJORD R |
|
Type |
Split hopper suction dredger |
|
IMO-number |
9588122 |
|
Call sign |
OYOZ2 |
|
Flag |
Denmark |
|
Port of registry |
Grenaa |
|
GT |
5.189 t |
|
DWT |
6.185 t |
|
NT |
1.556 t |
|
Length |
111,30 m overall 103,45 m between perpendiculars |
|
Breadth |
19,40 m |
|
Draught |
7,00 m loaded 3,70 m unloaded |
|
Freeboard |
2.546 mm |
|
Depth |
7,70 m |
|
Speed |
14,0 knots loaded 15,3 knots empty |
|
Built |
2011 |
|
Date of completion |
13/10/2011 |
|
Builder |
Peene-Werft GmbH & Co., KG Wolgast Germany |
|
Yard number |
569 |
|
Hull material |
Steel |
|
Main engine |
2x Electro-Motive Diesel EMD 16-71067C-T2 combustion engines each 2.985 kW |
|
Propelling system |
2x Azimuth thruster controllable pitch |
|
Shaft generator |
2x Each 1.875 kVA - 1.600 kW |
|
Bow thruster |
2x Jastram BU 60 F each 450 kW |
|
Pump ashore power |
2x Deutz engines each 2.350 kW |
|
Total installed power |
11.075 kW |
|
Number of holds |
1 |
|
Hopper capacity |
6.000 m³ |
|
Suction pipe |
2x 700 mm |
|
Dredging depth |
35,00 m standard Max: 65,00 m |
|
Tank capacities |
Fuel oil: 595,2 m³ |
|
Crew |
11 |
|
Manager |
Rohde Nielsen A/S Amager Strandvej 403 DK-2770 Kastrup Denmark |
|
Registered owner |
RN Shipping AS Care of Rohde Nielsen A/S Amager Strandvej 403 DK-2770 Kastrup Denmark |
|
Latest data adjustment |
26 June 2022 |
