| Westerschelde 03 October 2014 |
|
Name |
TOMKE |
|
Type |
Multi-purpose vessel - Strengthened for heavy cargo |
|
IMO-number |
9197806 |
|
Call sign |
YLKQ |
|
Flag |
Latvia |
|
Port of registry |
Riga |
|
Previous flags |
Gibraltar - Call sign: ZDEC9 |
|
GT |
2.301 t |
|
DWT |
Summer: 3.171 t |
|
NT |
1.289 t |
|
Number of 20ft containers |
In hold: 96 On deck: 36 Total: 132 |
|
Reefer capacity |
None |
|
Length |
82,50 m over all 78,90 m between perpendiculars |
|
Breadth |
12,40 m |
|
Draught |
5,30 m |
|
Freeboard |
1.409 mm |
|
Depth |
6,70 m |
|
Speed |
12,5 knots |
|
Built |
2000 |
|
Date of completion |
29/06/2000 |
|
Builder casco |
Daewoo Mangalia Heavy Industries S.A. Yard number: 1007 |
|
Builder completion |
Scheepswerf Waterhuizen J.pattje The Netherlands Yard number: 416 |
|
Hull material |
Steel |
|
Hull type |
Double skin |
|
Watertight compartments |
5 |
|
Movable bulkhead |
2x Movable bulkheads consisted of 4 pcs, placeable in 7 positions |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 6M25 - 4 stroke 6 cylinder 255 x 400 mm combustion engine 1.800 kW / 2.446 hp at 750 rpm Built: 28.01.2000 Builder: Mak, Kiel - Germany |
|
Propellers |
1x Screw propeller controllable pitch - aft at 220 rpm |
|
Shaft generator |
300 kVA / 240 kW |
|
Generators |
2x MAN D2866E diesel generatorsets each 125 kW |
|
Emergency generator |
1x MAN D2866E diesel generatorsets 116 kW |
|
Bow thruster |
1x Jastram Bu 40 F - 240 kW |
|
Number of holds |
1 55,00 x 10,20 x 8,45 m |
|
Cargo hold capacity |
Bales / grain: 167.400 ft³ / 4.782 m³ Timber: 4.350 m³ |
|
Hatch type |
Pontoons with gantry crane |
|
Ventilation |
6x Air changes per h |
|
Fuel capacity |
217 m³ |
|
Operator |
International Shipbrokers London |
|
Registered owner |
Ventura Schiffahrts GmbH & Co KG ms 'Tomke' |
|
Renamed |
06/2019 Vardefjell Norway, Flekkefjord - Call sign: LAHY8 Owner: AAT Shipinvest AS, 4401 Flekkefjord - Norway Manager: Reederei Eilbrecht Gmbh & Co KG |
|
Latest data adjustment |
17 August 2017 |
