Name |
PROMISE 3 |
|
Previous names |
25/10/2010 - 23/01/2011 Aktor II 23/01/2011 - 23/01/2011 Promise 3 23/01/2011 - 28/01/2011 Aktor II |
|
Type |
Bulk carrier - Carriage of dangerous goods |
|
IMO-number |
9571404 |
|
Call sign |
VRHZ5 |
|
Flag |
Hong Kong - Special Administrative Region of the People's Republic of China |
|
Port of registry |
Hong Kong |
|
Previous flags |
|
|
GT |
22.927 t registered Suez: 23.703,89 t |
|
DWT |
Summer: 32.311,65 t |
|
NT |
10.616 t registered Panama: 19.102 t Suez: 21.282,29 |
|
Length |
180,92 m overall |
|
Breadth |
30,00 m moulded |
|
Reg. dimensions L x B x D |
173,27 x 30,00 x 14,80 m |
|
Rule dimensions L x B x D |
173,03 x 30,00 x 14,80 m |
|
Freeboard |
5.027 mm |
|
Depth |
14,80 m moulded |
|
Speed |
14,5 knots |
|
Built |
2010 |
|
Keel laid |
12/04/2010 |
|
Launch date |
28/07/2010 |
|
Delivery date |
22/10/2010 |
|
Builder |
Samho Shipbuilding Co., Ltd. Tongyoung South Korea |
|
Yard number |
SH1225 |
|
Hull material |
High strength steel Ordinary strength steel |
|
Hull type |
Double hull |
|
Watertight bulkheads |
8 |
|
Main engine |
1x MAN-B&W/HHI 6S46MC-C7 - 2 stroke single acting 6 cylinder 460 x 1.932 mm combustion engine 7.860 kW at 129,0 rpm Build: 04/2010 Manufacturer: Hyundai Heavy Industries Co., Ltd., Engine & Machinery Division, Ulsan - South Korea |
|
Propellers |
1 Manufacturer: Hae Yang Metal Co., Ltd. |
|
Boilers |
1x Composite Boiler - 9,0 bar Heating surface: 47,0 m² Build: 05/2010 Manufacturer: Aalborg Industries Ltd. |
|
Generators |
3x Diesel generatorsets each 550 kW / 687 kVA - 450 Volt Manufacturer: HHI Electro Electric System |
|
Number of holds |
5 |
|
Cargo hold capacity |
Bale: 42.867,1 m³ grain: 46.178,2 m³ |
|
Number of tanks |
Ballast: 12 Fuel oil: 12 Lubricating oil: 11 Diesel oil: 4 Fresh water: 4 Chain: 2 Waste water: 2 Sludge: 2 Sewage: 2 |
|
Tank capacities |
Diesel Oil: 188,2 m³ Freshwater: 380,4 m³ Fuel Oil: 1.695,2 m³ Lube Oil: 145,5 m³ Tank Ballast: 11.692,2 m³ |
|
Lifting equipment |
1x E/R overhead crane - SWL 3,0 t Manufacture: Dae Kyung Co., Ltd. 1x Provision crane - SWL 3,0 t Manufacture: Dongnam Marine Crane Co., Ltd. |
|
Cargo gear |
4x Deck crane - SWL 30,0 t each Manufacture: Nantong Rainbow Heavy Machinerics Co., Ltd. |
|
Manager |
STX Marine Service Co., Ltd. Panocean Building 102 Jungang-daero Jung-gu Busan 600-725 South Korea |
|
ISM Manager |
Fleet Management Hong Kong Hong Kong China |
|
Owner |
Promy 3 Limited Corp. Suite B, 12/F, Two Chinachem Plaza 135 Des Voeux Road Central Hong Kong China |
|
Registered owner |
Promy 3 Limited Corp. Care of Cargill International SA Chemin de Normandie 14 1206 Geneva Switzerland |
|
Renamed |
2022 Woohyun Sky South Korea, Jeju - Call sign: D7XE Owner a Manager: Woohyun Shipping Co., Ltd. Technical manager: W Ocean Co., Ltd. |
|
Latest data adjustment |
29 June 2023 |
