| Antwerpen 11 august 2015 |
 |
| Antwerpen 31/08/11 |
|
Name |
DIAMAR |
|
Previous names |
2005 Solution 2009 Solution II 2010 Diamar |
|
Type |
Inland tanker |
|
ENI-number |
02327108 |
|
Flag |
Germany |
|
Port of registry |
Wörth a/ Main |
|
GT |
2.211 t |
|
DWT |
2.991 t |
|
Length |
109,95 m |
|
Breadth |
11,45 m |
|
Draught |
3,60 m |
|
Depth |
5,35 m |
|
Built |
2005 |
|
Date of completion |
09.09.2005 |
|
Builder casco |
Malbo & Konstrukcje |
|
Builder completion |
Dolderman |
|
Yard number |
52 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Continuous decks |
1 |
|
Main engine |
1x Caterpillar 3516 (B) Low speed - 4 stroke 16 cylinder diesel engine - 1.305 kW / 1.773 hp at 1.200 rpm Built: 2005 Builder: Caterpillar Inc., Lafayette (Indiana) (USA) |
|
Propelling system |
1x Screw propeller solid 5-blades propeller, diameter 1.750 mm turning right with nozzle type Optima diameter 1.762 mm |
|
Shaft generator |
1x 593 kVA - 474 kW |
|
Generators |
2x John Deere type 6068 TF 258 diesel generatorsets each 204 kVA - 163 kW |
|
Bow thruster |
1x Caterpillar 3412 E - Verhaar Omega-Jet - 643 hp |
|
Tank capacity |
3.800 m³ |
|
Owner |
Shalma Tankschiffahrt in |
|
Previous names & owners |
2005 Solution - Vof. Solution, Hendrik-Ido-Ambacht - The Netherlands 2009 Solution II - Vof. Solution, Hendrik-Ido-Ambacht - The Netherlands 2010 Diamar - Shalma Tankschiffahrt, Schmachtenhagen - Germany |
|
Latest data adjustment |
13 December 2015 |
