Name
|
MIEDWIE
|
|
Type
|
Single deck, Double skinned, open hatch, self-trimming bulk carrier - Handysize
|
|
IMO-number
|
9393448
|
|
Call sign
|
9HA5757
|
|
Flag
|
Malta
|
|
Port of registry
|
Valletta
|
|
Previous flag
|
Bahamas, Nassau – Call sign: C6XP5
|
|
GT
|
20.603 t
|
|
DWT
|
Summer: 30.481 t
Winter: 29.483 t
|
|
NT
|
9.932 t
|
|
Length
|
190,00 m overall
182,60 m between perpendiculars
|
|
Breadth
|
23,76 m extreme
23,59 m moulded
|
|
Draught
|
Summer: 10,22 m
Winter: 10,00 m
|
|
Depth
|
14,60 m moulded
|
|
Speed
|
Laden: 13,0 knots - Economic: 11,5 knots
Ballast: 13,5 knots - Economic: 12,0 knots
|
|
Built
|
2010
|
|
Keel laid
|
03/09/2008
|
|
Launch date
|
11/08/2009
|
|
Date of completion
|
22/03/2010
|
|
Builder
|
Nantong Mingde Heavy Industry Co., Ltd.
Nantong
China
|
|
Yard number
|
MD016-30000LBC-01
|
|
Hull material
|
Steel
|
|
Continuous decks
|
1
|
|
Main engine
|
1x Wärtsilä 6RTA48TB – 2 stroke 6 cylinder 480 x 2.000 mm combustion engine 8.730 kW / 11.869 hp at 127,0 rpm
Builder: Diesel United Ltd., Aioi - Japan
|
|
Propellers
|
1x Controllable pitch propeller
|
|
Boilers
|
1x Auxiliary boiler, composite
Builder: Zhangjiagang Greens Shazhou Boiler Co., Ltd.
|
|
Bow thruster
|
1x 1.250 kW
|
|
Generators
|
2x Wärtsilä 4L20 diesel generatorsets each 680 kW
1x Wärtsilä 6L20 diesel generatorset each 875 kW
Builder: Wärtsilä Finland Oy
|
|
Emergency generator
|
1x Volvo Penta D9A MG diesel generatorset 265 kW
|
|
Number of holds
|
6
Hold 1: 19,20 x 20,86 x 14,70 m
Hold 2: 25,60 x 21,20 x 14,70 m
Hold 3: 25,60 x 21,20 x 14,70 m
Hold 4: 25,60 x 21,20 x 14,70 m
Hold 5: 25,60 x 21,20 x 14,70 m
Hold 6: 20,80 x 21,20 x 14,70 m
|
|
Cargo hold capacity
|
Grain:
Hold 1: 5.008,9 m³ / 176.887,65 ft³
Hold 2: 7.102,1 m³ / 250.808,32 ft³
Hold 3: 7.115,3 m³ / 251.274,47 ft³
Hold 4: 7.115,5 m³ / 251.281,53 ft³
Hold 5: 7.116,0 m³ / 251.299,19 ft³
Hold 6: 5.664,9 m³ / 200.054,07 ft³
Total : 39.122,7 m³ / 1.381.605,2 ft³
|
|
Number of hatches
|
6
Hatch 1: 12,80 x 12,80 x 1,80 m
Hatch 2: 19,20 x 17,80 x 1,80 m
Hatch 3: 19,20 x 17,80 x 1,80 m
Hatch 4: 19,20 x 17,80 x 1,80 m
Hatch 5: 19,20 x 17,80 x 1,80 m
Hatch 6: 16,80 x 17,80 x 1,80 m
|
|
Tank capacities
|
Ballast: 17.035 m³
|
|
Lifting equipment
|
Length: 605,00 m
Diameter: 64 mm
|
|
Cargo gear
|
3x Deck cranes – SWL 30,0 t each
Grabs: 3x 24,0 t
|
|
Crew size
|
30
|
|
ISM & commercial manager
|
Polska Żegluga Morska Przedsiębiorstwo Państwowe
Plac Rodla 8
70-419 Szczecin
Poland
|
|
Operator
|
Polsteam Shipping Ageny Ltd.
|
|
Registered owner
|
Erato One Shipping Ltd.
Care of Polska Zegluga Morska PP (POLSTEAM)
Plac Rodla 8
70-419 Szczecin
Poland
|
|
Latest data adjustment
|
11 May 2024
|
