Westerschelde 27 June 2017 |
 |
 |
 |
 |
|||
| Antwerpen 07/05/15 | Antwerpen 07/05/15 | Antwerpen 26/05/16 | Westerschelde 31/07/17 | |||
|
Name |
SAOURA |
|
Previous names |
2012 - 08/2014 Clipper Gemini |
|
Type |
Multi-purpose general cargo ship |
|
IMO-number |
9557800 |
|
Call sign |
7THA |
|
Flag |
Algeria |
|
Port of registry |
Alger |
|
Previous flag |
2012 - 08/2014 Bahamas, Nassau |
|
GT |
8.161 t Panama: 7.318 Suez: 8.414,14 t |
|
DWT |
Summer: 9.095 t |
|
NT |
3.430 t Suez: 6.390,47 t |
|
Light ship |
5.301,2 t excluding tween deck |
|
Displacement |
Summer: 13.987 t |
|
Number of 20ft containers |
681 |
|
Reefer plugs |
100 |
|
Length |
119,85 m overall 112,00 m between perpendiculars |
|
Breadth |
20,40 m moulded 20,70 m extreme |
|
Draught |
Summer: 8,45 m |
|
Mast head above keel |
44,80 m 41,30 m when mast is down |
|
Distance bow to bridge |
106,35 m |
|
Distance bridge to stern |
13,50 m |
|
Depth |
11,10 m moulded |
|
Speed |
16,0 knots loaded 17,0 knots ballast |
|
Built |
2012 |
|
keel laid |
27/06/2010 |
|
Date of completion |
11/01/2012 |
|
Builder |
Yangfan Group Co. Ltd. Zhoushan China |
|
Yard number |
H2144 |
|
Hull material |
Steel |
|
Continuous decks |
1 |
|
Main engine |
1x MAN-B&W 6S42MCT - 6 cylinder combustion engine 6.480 kW |
|
Propellers |
1 |
|
Generators |
3x Diesel generatorsets each 792 kW at 720 rpm - 450 VAC 60 Hz |
|
Emergency generator |
1x Diesel generatorset 200 kW at 1.800 rpm - 450 VAC - 60 Hz |
|
Bow thruster |
1x Pitch propeller 600 kW |
|
Number of holds |
1 65,6 x 15,30 x 11,694 m |
|
Cargo hold capacity |
Bale: 11.064,3 m³ Grain: 11025,6 m³ |
|
Max permitted loads |
Tank top: 20 t/m² |
|
Tank capacity |
Ballast capacity: 4.466,8 m³ Fresh water: 123 m³ Heavy fuel oil 98%: 941,4 m³ Gas oil: 121 m³ Lubrication oil: 86,2 m³ |
|
Anchor equipment |
2x Weight: 6.300 kg each |
|
Cargo gear |
2x MacGregor deck cranes - SWL 200 t each |
|
Manager |
CNAN Nord Spa |
|
Operator |
CNAN Nord |
|
Registered owner |
CNAN El Djazair SpA 74, boulevard Mohamed V Alger Algeria |
|
Previous names & owners |
2012 - 08/2014 Clipper Gemini - Clipper Project Shipping, Nassau - Bahamas |
|
Latest data adjustment |
25 September 2024 |
