Name |
BOW FORTUNE |
|
Type |
Tanker for chemicals & oil products |
|
IMO-number |
9168635 |
|
Call sign |
V7A5150 |
|
Flag |
Marshall Islands |
|
Port of registry |
Majuro |
|
Previous flags |
1999 - 2022 Norway, Bergen - Call sign: LAJQ5 |
|
GT |
23.206 t Suez: 23.386 t |
|
DWT |
Summer: 37.395 |
|
NT |
11.915 t Suez: 20.699 t Panama: 19.334 t |
|
Light ship |
11.103 t |
|
Length |
183,10 m overall 176,90 m between perpendiculars |
|
Breadth |
32,20 m extreme |
|
Draught |
Summer: 10,72 m |
|
Keel to mast end |
43,36 m |
|
Speed |
Max.: 16,0 knots Service: 14,3 knots |
|
Built |
1999 |
|
Keel laid |
04/08/1998 |
|
Launch date |
25/02/1999 |
|
Date of completion |
12/05/1999 |
|
Builder |
Kværner Florø AS Florø Norway |
|
Yard number |
138 |
|
Hull material |
Steel |
|
Hull type |
Double bottom Double side with top wing |
|
Bulkheads |
Transverse: 7 |
|
Continuous decks |
1 |
|
Main engine |
1x Kawasaki/MAN-B&W 6L60MC MK-V - 2 stroke 6 cylinder 600 x 1.944 mm combustion engine 10.409 kW / 14.152 hp at 123,0 rpm |
|
Propellers |
1x Controllable pitch propeller |
|
Boilers |
1x Auxiliary boiler, exhaust gas heated AV-6N 2x Auxiliary boiler, oil/gas fired AQ9 Builder: Aalborg |
|
Generators |
2x MAN-B&W 6L28/32H main diesel generatorsets |
|
Emergency generator |
1x Volvo TMD 122 A diesel generatorset |
|
Bow thruster |
1x 883 kW |
|
Number of cargo tanks |
47 |
|
Cargo tank capacity |
Total centre tanks: 21.584 m³ Total wing tanks: 17.615 m³ Grand total: 39.799 m³ |
|
Number of pumps |
5x Cargo pumps each 500 m³/h 10x Cargo pumps each 300 m³/h 28x Cargo pumps each 200 m³/h |
|
Manifolds |
Summer draft to manifold: 5,60 m Rail to manifold: 4,50 m Bow to manifold: 95,30 m |
|
Tank capacities |
Ballast: 15.034 m³ |
|
Commerical manager |
Odfjell Asia Ii Pte Ltd. 27-08/9, OUE Downtown 2, 6, Shenton Way Singapore 068809 Republic of Singapore |
|
ISM manager |
Odfjell Management AS Conrad Mohrs veg 29 5072 Bergen Norway |
|
Registered owner |
Goldex Fortune Ltd. Care of Bocimar International NV De Gerlachekaai 20 2000 Antwerpen Belgium |
|
Latest data adjustment |
05 September 2023 |
