Zeebrugge 04 March 2024 |
 |
 |
 |
 |
 |
 |
|||||
| Zeebrugge 04/03/24 | Zeebrugge 04/03/24 | Westerschelde 30/09/19 | Westerschelde 08/10/17 | Westerschelde 08/10/17 | Vlissingen 22/10/20 | |||||
 |
||||||||||
| Vlissingen 18/05/16 | ||||||||||
|
Name |
SEA BRONCO |
|
Previous names |
2006 - 2013 Smit Bronco |
|
Type |
Tug - Push boat - Multi-purpose vessel Special service dredging assistance unit Delta multi purpose pusher tug 2500 |
|
IMO-number |
9345491 |
|
Call sign |
MNFJ6 |
|
Flag |
United Kingdom |
|
Port of registry |
Brixham |
|
Previous flags |
2006 - 2012 The Netherlands 2012 - 2012 St. Vincent and Grenadines 2012 - 2014 The Netherlands 2014 - 2015 Cyprus, Limassol - Call sign: 5BAA4 2015 - 2023 The Netherlands, Vlissingen - Call sign: PHFS |
|
GT |
230 t |
|
DWT |
Summer: 120 t |
|
NT |
69 t |
|
Length |
25,45 m overall 23,67 m between perpendiculars |
|
Breadth |
10,05 m overall |
|
Draught |
Min: 2,50 m Operating: 2,60 m Max: 2,72 m |
|
Air draft |
Min: 9,10 m Max: 26,33 m |
|
Depth |
3,45 m |
|
Speed |
Max: 10,5 knots Economic: 8,0 knots |
|
Built |
2006 |
|
Keel laid |
31/12/2005 |
|
Date of completion |
16/05/2006 |
|
Builder |
IHC Holland BV Sliedrecht The Netherlands |
|
Yard number |
11016 |
|
Hull material |
Steel |
|
Watertight compartments |
5 |
|
Continuous decks |
1 |
|
Main engine |
2x Caterpillar CAT 3508B - 4 stroke 8 cylinder 170 x 190 mm combustion engines each 746 kW Total 1.492 kW / 2.028 bhp at 1.600 rpm Built: 2005 Builder: Caterpillar Inc., Lafayette, IN - USA |
|
Gearbox |
2x Reintjes WAF-562L- reduction: 5.424:1 |
|
Propelling system |
2x Screw propeller solid at 295 rpm Diameter: 2.000 mm |
|
Electric installations |
Power voltage: 400 V Lighting voltage: 220 V Frequency: 50 Hz |
|
Generators |
2x Caterpillar CAT 3056T - 6 cylinder 100 x 127 mm combustion engine each 84 kW coupled with 2 Leroy Somer generators each 105 kVA |
|
Bow thruster |
1x Veth Jet Jet hydraulically driven thruster 150 kW |
|
Bollard pull |
28,27 t |
|
Deck equipment |
Free deckspace: 52,0 m² Deck strength: 5,0 t/m² Towing winch: Kraaijeveld 50 t / 70 t (pull / hold) 700 m x 38 mm Anchor handling winch: 50 t / 70 t (pull / hold) 200 m x 44 mm Towing pins: Shark Jaw Fork - SWL 50,0 t Pushbow: Full length rubber fendered Stern roller: SWL 100 t |
|
Fuel oil transfer pump |
12 m³/h |
|
Fresh water transfer pump |
12 m³/h |
|
Tank capacities |
Fuel oil: 66,2 m³ Fresh water: 37,2 m³ Lubrication oil: 2,4 m³ Dirty oil: 3,4 m³ Sewage; 2,6 m³ Bilge water: 2,4 m³ Hydraulic oil: 3,4 m³ |
|
Lifting equipment |
1x Heila HLRM 140-3S deck crane - SWL 10,0 t @ 12,30 m |
|
Accommodation |
Persons: 6 Single cabins: 2 Double cabins: 2 |
|
Crew |
5 |
|
Navigation & communications |
1x JRC JMA 5104 Radar 1x JRC JMA 609 Radar 1x Cassens & Plath Magnetic Compass 1x JCR JLR10 GPS Compass 1x Ratheon Autopilot 1x Anschutz Autopilot 1x JRC NAV 500 GPS 1x Furuno FE 700 Echo Sounder 1x Sailor RT 4822 VHF 1x Sailor RT 2048 VHF 3x McMurdo R2 Handheld VHF 1x JRC NCR Navtex 1x Sailor HT 4610 MF/HF Radio 1x Furuno FA 150 AIS |
|
Manager |
Seacontractors BV Visserijkade 95, 4382 ZA Vlissingen The Netherlands |
|
Registered owner |
Sea Bronco BV |
|
Previous owners |
2006 - 2009 Smit Transport Europe BV, Rotterdam - The Netherlands 209 - 2015 Smit Nassau Bahamas - Bahamas |
|
Latest data adjustment |
08 March 2024 |
