Westerschelde 05 March 2016 |
 |
 |
|
| Westerschelde 28/02/16 | Westerschelde 30/06/15 | |
|
Name |
STAR LOEN |
|
Type |
Open hatch general cargo ship / Containership |
|
Main products |
Baled pulp, ore, grain, cement, paper, packaged lumber and other solid bulk cargoes |
|
IMO-number |
9603790 |
|
Call sign |
LAQN7 |
|
Flag |
Norway |
|
Port of registry |
Bergen |
|
GT |
37.447 t |
|
DWT |
Summer: 50.792 t |
|
NT |
15.619 t |
|
Length |
204,37 m overall 194,03 m between perpendiculars |
|
Breadth |
32,31 m extreme 32,26 m moulded |
|
Draught |
12,64 m |
|
Air draft |
Max.: 51,11 m Max.: 47,00 m mast folded |
|
Depth |
19,00 m to main deck |
|
Speed |
15,5 knots |
|
Built |
2013 |
|
Keel laid |
19/04/2013 |
|
Launch date |
14/06/2013 |
|
Date of completion |
16/09/2013 |
|
Builder |
Hyundai Mipo Dockyard Co., Ltd. Ulsan South Korea |
|
Yard number |
8081 |
|
Hull material |
Steel |
|
Main engine |
1x Hyundai/MAN B&W 5S60ME-C8.1 - 2 stroke 5 cylinder combustion engine 10.780 kW at 95,2 rpm |
|
Propellers |
1x Fixed pitch propeller |
|
Boilers |
1x Auxiliary Boiler type: PA0101P12 Steam production: 1.600 kg/h Working pressure: 7 kg/cm² 1x Exhaust gas economizer type: EM12RD12A4 Steam production: 1.200 Kg/h Working pressure: 7 kg/cm² Exhaust gas amount: 87 000 Kg/h Builder: Kangrim Heavy Industries Co., Ltd. |
|
Generators |
3x Hyundai Himsen 5H21/32 - 4 stroke 5 cylinder diesel engine each 960 kW at 900 rpm connected with HFC7 506-84K generators each 1.125 kVA / 900 kW Builder: Hyundai Heavy Industries Co., Ltd. |
|
Emergency generator |
1x Sisu diesel generatorset 225 kVA / 180 kW |
|
Compressed air receivers |
2x Main air compressors: Sperre XW150 165 m³/h capacity at 30,0 bar 1x Working air compressor: Atlas Copco GA37VSD-175-60 - 388 m³/h at 7,0 bar 1x Emergency air compressor: Sperre XA030 - 35 m³/h at 30,0 bar |
|
Number of holds |
9x Box-shaped cargo holds |
|
Cargo hold capacity |
Bale: No. 1: 4.522 m³ / 159.711 ft³ No. 2: 5.959 m³ / 210.443 ft³ No. 3: 14.298 m³ / 504.926 ft³ No. 4: 6.932 m³ / 244.814 ft³ No. 5: 6.932 m³ / 244.814 ft³ No. 6:14.298 m³ / 504.926 ft³ No. 7: 6.557 m³ / 231.571 ft³ No. 8: 5.398 m³ / 190.296 ft³ No. 9: 1.886 m³ / 66.619 ft3 Total: 66.773 m³ / 2.358.120 ft³ Two removable tweendecks in hold no 4 and 7 |
|
Number of hatches |
9 |
|
Hatch type |
8x Piggy back hatch covers 1x Folding type hold 1 |
|
Max. permitted loads |
Weather deck hatch covers: 3,6 t/m² Tween decks: 5,5 t/m² Tank top-Hold 2 to 8: 28,0 t/m² Tank top-Hold 9: 5,5 t/m² |
|
Hold ventilation |
Hold 1-2: 6 air changes per hour Hold 3-8: 2 air changes per hour |
|
Tank capacities |
Ballast: 20.365 m³ |
|
Lifting equipment |
Length: 660,00 m Diameter:78 mm |
|
Cargo gear |
4x Cargotec/MacGregor slewing cranes on deck - SWL 75,0 t each |
|
Accommodation |
Accommodation aft for a total of 29 persons |
|
Manager |
Grieg Star AS C Sundtsgate 17-19 5004 Bergen Norway |
|
Operator |
Grieg Star |
|
Registered owner |
Grieg Shipping II AS / Grieg International II AS C Sundtsg 17-19 5004 Bergen Norway |
|
Previous owners |
2013 - 2013 Grieg Shipping Group |
|
Latest data adjustment |
05 May 2023 |
