Zeebrugge 11 May 2018 |
 |
| Zeebrugge13/05/15 |
|
Name |
EUPHONY ACE |
|
Type |
Roll-On/Roll-Off vehicle carrier Pure Car and Truck Carrier |
|
IMO-number |
9293595 |
|
Call sign |
3EDG6 |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GT |
58.631 t registered |
|
DWT |
Summer: 18.944 t |
|
NT |
17.590 t registered |
|
Length |
199,95 m overall |
|
Breadth |
32,26 m |
|
Draught |
Summer: 9,82 m |
|
Moulded L x B x D |
190,00 x 32,20 x 14,70 m |
|
Registered L x B x D |
192,86 x 32,20 x 21,19 m |
|
Freeboard |
4.914 mm |
|
Speed |
Max.: 22,4 knots Service: 20,7 knots |
|
Built |
2005 |
|
Keel laid |
04.11.2004 |
|
Launch date |
27.07.2004 |
|
Date of completion |
18.11.2005 |
|
Builder |
Minaminippon Shipbuilding Co., Ltd. |
|
Yard number |
688 |
|
Hull material |
Steel |
|
Main engine |
1x 2 stroke single acting 8 cylinder 600 x 2.300 mm diesel engine 15.130 kW at 100,0 rpm Manufacturer: Kobe Diesel Co., Ltd. Nagasaki Works |
|
Propeller shaft |
1x Oil lubrication shaft with monitoring device Diameter: 620 mm |
|
Propellers |
1 |
|
Boilers |
1x Auxiliary vertical boiler - 7,8 bar Evaporation: 4,01 t/h Manufacturer: Tortoise Engineering Co., Ltd. |
|
Generators |
4x Generators - 3.900 kVA |
|
Number of cars |
5.214 |
|
Tank capacities |
Fuel oil: 2.956 m³ Fresh water: 671 m² Water ballast: 7.233 m³ |
|
Crew |
27 |
|
Manager |
MOL Shipmanagement Singapore Pte. Ltd. |
|
Operator |
MOL - Mitsui O.S.K. Lines |
|
Owner |
Mol Shipmanagement |
|
Registered owner |
Aurora Car Maritime Transport S.A. |
|
Remarks |
The Euphony Ace, launched in 2005, and the Swift Ace launched in 2008 features a solar power generation panel which uses natural energy installed on the deck |
|
Latest data adjustment |
13 June 2018 |
